What is the adaptive defrost control?
Check!
Adaptive Defrost Control
"Oh No--Not again!"
This is a FREE information site!
Part of EdDx Educational Series
>>>
PHOTOS and ILLUSTRATIONS
on this site<<<
Does your refrigerator have a mechanical timer or an adaptive defrost control?
The adaptive defrost control basically does the same job as a defrost timer and more. Like the defrost timer, it shuts off the refrigerator cooling devices and redirects the power to the defrost heater for the defrosting cycle. It then redirects the power to the compressor and fans to come back on when the defrost cycle is over. Some also record and make calculations to help make the cycle more accurate.
You may have had this board replaced a short time ago. Yes, the new one can become defective over time! Just replacing it once is no guarantee that you will not have to replace it--again!
1/4
Know your limitations and call a repair person if necessary!
UNPLUG the Refrigerator!
Can we assume that your refrigerator is empty, since you are replacing the ADC? The refrigerator/ freezer should be empty to help you work and to avoid contaminating/ruining food. Do you really know how long it will take to effect a repair? >>>Food Storage TIPS!
For more information and/or to illustrate, you can right click on some photos/images to enlarge them for a better view. Move your mouse over a word or photo and it will change if it is a link (highlight, change color, a hand may appear).
First, become familiar with the parts and location!
The adaptive defrost assembly (ADC) on this model is located in the refrigerator compartment. Your model may differ from the illustrations, but the same principles apply.
Top of the
Refrigerator Compartment
ADC location (in red area) up under the refrigerator light panel
ADC
If your refrigerator is an "older model" or has never had the
ADC
replaced, you will probably find an uncovered computer board.
Here is a view from above (inside) with the
control panel
pulled down slightly.
The hardest part of this repair is removing the plastic cover in the ceiling of the refrigerator compartment to get to the ADC. Lots of photos, illustrations and step-by step instructions to ease your pain coming up.
Parts
Admiral Refrigerator Parts Amana Refrigerator Parts Caloric Refrigerator Parts Electrolux Refrigerator Parts Frigidaire Refrigerator Parts GE Refrigerator Parts Hotpoint Refrigerator Parts Jenn-Air Refrigerator Parts Kenmore Refrigerator Parts (Sears) KitchenAid Refrigerator Parts Magic Chef Refrigerator Parts Maytag Refrigerator Parts Roper Refrigerator Parts Tappan Refrigerator Parts Whirlpool Refrigerator Parts White-Westinghouse Refrigerator Parts
EducationDx
©2016, 2023
Your refrigerator
can have one or the other, not both! The adaptive defrost control (ADC) is usually behind a cover, so you cannot see it like you see the ice maker. You can tell by the brand name and model number or by taking the refrigerator apart--you decide. (locate model number tag)
Remember to test your defrost heater and thermostat first. If they test out okay, replace the ADC.
Help Locating the ADC
This is a FREE information site!
Part of EdDx Educational Series
www.EducationDx.com
Note: Larger computer screens will show larger materials!
Adaptive Defrost Control
Does your refrigerator have a mechanical timer or an adaptive defrost control?
Check!
Know your limitations and call a repair person if necessary!
Your refrigerator
can have one or the other, not both! The adaptive defrost control (ADC) is usually behind a cover, so you cannot see it like you see the ice maker. You can tell by the brand name and model number or by taking the refrigerator apart--you decide. (locate model number tag)
"Oh No--Not again!"
What is the adaptive defrost control?
The adaptive defrost control basically does the same job as a defrost timer and more. Like the defrost timer, it shuts off the refrigerator cooling devices and redirects the power to the defrost heater for the defrosting cycle. It then redirects the power to the compressor and fans to come back on when the defrost cycle is over. Some also record and make calculations to help make the cycle more accurate.
You may have had this board replaced a short time ago. Yes, the new one can become defective over time! Just replacing it once is no guarantee that you will not have to replace it--again!
Remember to test your defrost heater and thermostat first. If they test out okay, replace the ADC.
UNPLUG the Refrigerator!
Can we assume that your refrigerator is empty, since you are replacing the ADC? The refrigerator/ freezer should be empty to help you work and to avoid contaminating/ruining food. Do you really know how long it will take to effect a repair? >>>Food Storage TIPS!
First, become familiar with the parts and location!
The adaptive defrost assembly (ADC) on this model is located in the refrigerator compartment. Your model may differ from the illustrations, but the same principles apply.
ADC location (in red area) up under the refrigerator light panel
If your refrigerator is an "older model" or has never had the
ADC
replaced, you will probably find an uncovered computer board.
Here is a view from above (inside) with the
control panel
pulled down slightly.
The hardest part of this repair is removing the plastic cover in the ceiling of the refrigerator compartment to get to the ADC. Lots of photos, illustrations and step-by step instructions to ease your pain coming up.
